IR Infrared Borescope

  • IR Infrared Borescope
  • IR Infrared Borescope

E-vision’s IR infrared borescopes feature lightweight, compact and versatile portable systems that make them ideal for use in military, police, fire and other fields. They allow for a fast, effective night vision detection for searching buildings, vehicles, ships, aircraft, and cargo.

Features and specifications
  • The portable integrated body completes every function with just one user’s hand.
  • 360° silent motor/mechanical control bending, accurate location
  • 5-inch 1080 dot matrix HD digital LCD touch screen to show the real environment; touch image to zoom in & out; 5 level brightness adjustment; adapt to complex conditions
  • audio and video recording; images can be edited online via touch screen; print report with one button
  • A 5600K white light source is available; realistic reduction of the detection target’s color environment
  • infrared/white/ultraviolet/three built-in light sources, freely switch between them
  • left and right split screen display, with real-time preview image on the left and reference image comparison on the right
  • 25500/18650 double lithium battery power supply, easy to replace, working period of 4 hours at a time
  • Removable sunshade, flexible change
  • multi-mode output, HDMI support; one operation can be shared to more than one person,
  • supports WiFi/bluetooth/wireless emission/4G and other multi-mode wireless image transmission systems (including image and audio synchronous recording)
  • 940nm IR infrared night vision system, a professional survey videoscope; clear night vision for objects 10 meters away
  • 6.0mm & 4.0mm probe specifications
Send an Inquiry
